Original Curtis PB-6 0-5K Ohm Throttle

Description

The PB-6 are out of production but the PB-8 is the same unit and you would just cap off the 3rd wire.

Link to the PB-8.

• Curtis Style PB-6
• The PB-6 is an input device between the Throttle pedal and the speed controller.
• Stainless case with a micro switch built in
• The potbox is the throttle in an EV
• The potbox tells the controller how much input needed by the controller
• The potbox’s lever arm is attached to the existing accelerator cable.
• Height: 3.75″, Width: 4″, Depth: 1.875″
• Weight: 10 oz
• Resistance: 0-5K ohms
